FEATURES

The Magnasine by Enerdrive products are designed and produced in the USA utilizing a tried and proven robust design platform, by a leading manufacturer of premium inverter/chargers for Mobile and Renewable Energy applications. With more than 70 years of combined inverter manufacturing and design experience, which has resulted in the MagnaSine by Enerdrive range being one of the industry’s most reliable and advanced inverter/chargers.

Install the ME series in four easy steps:

Simply connect the inverter’s output to your distribution circuits or electrical panel, connect your shore power cable (AC) to the inverter’s easy-to-reach terminal block, connect the batteries, and switch on the power.

USA Made and Proven Design

Massive Inverter Surge Capacity
High Output Charging
Easy to Install
Low Frequency Transformer Inverter

ME-ARC Remote Control

The ME-ARC remote control allows you to monitor and customize the operating parameters to your MagnaSine inverter/charger.

The ME-ARC comes standard with a 50 foot, 4-conductor (twisted-pair) telephone cable and includes non-volatile memory (preserves adjustable settings, even if power to the remote or inverter is removed). The MagnaSine remote control has all of the programming and operation functions included in an easy-to-use package.

ME-ARC displays:

Battery Voltage
Inverting
Battery Charging Status
Inverter Charger operating status and warnings
DC Load Amps, DC Amps Consumed and State of Charge (if ME-BMK Monitor Kit is being used)

Using the ME-ARC Remote Control, you can program:

Charging algorithm of the batteries
Battery Capacity
Battery Charge Efficiency Factor
Mains Current Limiter
Charging Rate
Mains AC Drop Out and Cut In
Power Save
Search Watts
Low Battery Cut Out

SPECIFICATIONS

Model	MS2712E - 12V	MS4124E - 24V	MS4348E - 48V
Inverter/Charger Specifications
Parallel Capable (Parallel stackable up to 4 units)	No	Yes (RTR Remote required)	Yes (RTR Remote required)
Input battery voltage range	9 – 17 Vdc	18 – 34 Vdc	36 – 68 Vdc
Nominal AC output voltage	230 Vac ±5%
Output frequency and accuracy	50 Hz ± 0.4 Hz
Total Harmonic Distortion (THD)	< 5%
1 msec surge current (amps AC)	45	65	75
100 msec surge current (amps AC)	21	30	37
5 sec surge power (real watts)	4100	6300	7500
30 sec surge power (real watts)	3750	5300	7100
5 min surge power (real watts)	3600	4750	6600
30 min surge power (real watts)	3500	4600	5000
Continuous power output (@ 25°C)	2700 VA	4100 VA	4300 VA
Maximum continuous input current	360 ADC	273 ADC	143 ADC
Inverter efficiency (peak)	86%	90%	91%
Transfer time	~ 20 ms
Search mode (typical)	9 watts	9 watts	10 watts
No load (230 VAC output, typical)	34 watts	30 watts	28 watts
Waveform	Pure Sine Wave
Charger Specifications
Continuous output @ 25°C	125 ADC	105 ADC	55 ADC
Charger efficiency (peak)	83%	88%	91%
Power factor	> .95	> .95	> .95
Input current at rated output (AC amps)	8.5	14	16
Transfer relay capability	30 amps AC
Five stage charging capability	Bulk, Absorb, Float, Equalize (requires remote), and Battery SaverTM
Battery temperature compensation	Yes, 4.6 m (15′) Battery Temp Sensor standard
Internal cooling	0 – 120 cfm variable speed drive using dual 92 mm brushless DC fans
Overcurrent protection	Yes, with two overlapping circuits
Over temperature protection	Yes on transformer, MOSFETS and battery
Conformal coating on PCBs for corrosion protection	Yes
Powder coated chassis & top for corrosion protection	Yes
Stainless steel fasteners for corrosion protection	Yes
Listings	C-Tick (Australian Standards)
Warranty	2 Years
Environmental Specifications
Operating temperature	-20°C – +60°C
Non-operating temperature	-40°C – +70°C
Operating humidity	0 – 95% RH non-condensing
Physical Specifications
Dimensions (H x W x L)	20.3 x 32.1 x 34.9 cm
Mounting	Shelf (top or bottom up) or wall
Weight	25.0 Kg
Shipping weight	28.2 Kg
