Description
Beny BDM series moulded case circuit breaker:
ZJ BENY BDM series PV DC moulded case circuit breaker (MCCB) are mainly used in large solar power systems which are applied for solar DC combiner box, inverter and DC power distribution cabinets. Rated voltage up to 500V DC, current up to 250A, with the function of overload protection and short circuit protection.
ZJ Beny:
ZJBENY is one of pioneer in China in the development, production and sales of PV DC Components, manufacturing DC Isolator, DC Combiner Box, DC Circuit Breaker, DC Fuse, DC SPD, with more than 25 years experiences in traditional electrical area, can provide powerful support for the renewable business, already obtained ISO9001 / SAA / TUV / UL/ ROHS / CB / CE certification.
FEATURES
- IP65 UV resistant enclosure for outdoor or indoor installation
- AS60947.2 and IEC 60947-2 standard
- Protection functions; Overload, short circuit, unfrequent operation
- High short circuit / breaking capacity
- Lockable transparent cover
- Rated voltage up to 500V DC
- Tested to extreme conditions -40 - +85 degrees Celsius
- Rated current 125A & 250A
SPECIFICATIONS
|
Brand: |
ZJBENY |
|
Model: |
BDM-125 |
|
Poles: |
2 Pole |
|
Standard: |
IEC60947.2, AS60947.2 |
|
Utilization category: |
DC-21B |
|
Rated operational voltage: |
500V |
|
Mechanical cycle: |
10000 |
|
Electrical cycle: |
2000 |
|
Protection degree: |
IP65 enclosure |
|
Polarity: |
No polarity |
|
Certificate: |
SAA / TUV |
|
Storage temperature: |
-40 to +85ºC |
|
Dimensions (LxWxH): |
150.5 x 64.5 x 119 mm |
|
Type of terminal: |
Screw terminal |
|
Suitable environment: |
Indoor / outdoor |
