Description
| PRODUCT NAME | Victron SmartSolar MPPT RS Solar Charge Controller 450/100-Tr SCC145110410 | Victron SmartSolar MPPT RS Solar Charge Controller 450/200-Tr SCC145120410 |
| DESCRIPTIONS | Experience versatile solar power management with the Victron SmartSolar MPPT RS Solar Charge Controller. This advanced controller optimizes solar energy utilization, ensuring efficient charging for your battery systems. | |
| FEATURES | MPPT: Ultra Fast Maximum Power Point Tracking | Multiple independent MPPT tracking inputs |
| Setup and monitor with VictronConnect | Isolated PV connections for additional safety | |
| Daisy Chain Additional Units | Wide MPPT voltage range | |
| Remote Monitoring and Control | Lightweight, efficient and quiet | |
| SmartSolar Display | Display and Bluetooth | |
| I/O Connections | ||
SPECIFICATIONS
| Product Name | Victron SmartSolar MPPT RS Solar Charge Controller 450/100-Tr SCC145110410 | Victron SmartSolar MPPT RS Solar Charge Controller 450/200-Tr SCC145120410 |
| Battery voltage | 48V | |
| Rated charge current | 100A | 200A |
| Maximum charge power | 5.8 kW at 57.6 V | 11.5 kW at 57.6 V |
| Charge voltage 'absorption’ | Default setting: 57.6V (adjustable) | |
| Charge voltage 'float' | Default setting: 55.2V (adjustable) | |
| Programmable voltage range | Minimum: 36V | |
| Maximum: 60V(7) | ||
| Charge algorithm | Multi-stage adaptive (adjustable) | |
| Battery temperature sensor | Included | |
| Maximum efficiency | 96% | |
| Self-consumption | 15 mA | |
| SOLAR | ||
| Maximum DC PV voltage | 450V | |
| Start-up voltage | 120V | |
| MPPT operating voltage range | 80 – 450V(1) | |
| Number of trackers | 2 | 4 |
| Max. PV operational input current | 18A per tracker | |
| Max. PV short circuit current(2) | 20A per tracker | |
| Max. DC output charging power | 4000W per tracker | 4000W per tracker |
| 5760W total | 11520W total | |
| Maximum PV array size per tracker(3) | 7200Wp (450V x 20A)(3) | |
| PV Isolation fail level(4) | 100kΩ | |
| GENERAL | ||
| Synchronised Parallel Operation | Yes, up to 25 units with VE.Can | |
| Programmable relay(5) | Yes | |
| Protection | PV reverse polarity | |
| Output short circuit | ||
| Over temperature | ||
| Data communication | VE.Direct port, VE.Can port & Bluetooth(6) | |
| Bluetooth frequency | 2402 – 2480MHz | |
| Bluetooth power | 4dBm | |
| General purpose analogue/digital in port | Yes, 2x | |
| Remote on-off | Yes | |
| Operating temperature range | -40 to +60°C (fan assisted cooling) | |
| Humidity (non-condensing) | max 95% | |
| ENCLOSURE | ||
| Material & Colour | steel, blue RAL 5012 | |
| Protection category | IP21 | |
| Battery-connection | M8 bolts | |
| Power terminals PV input | 2 16mm(2) | |
| Weight | 7.9kg | 13.7kg |
| Dimensions (h x w x d) in mm | 440 x 313 x 126 | 487 x 434 x 146 |
WARRANTY
Victron Energy warrants its products to be free from defects in workmanship and materials for a period of Batteries: 2-year limited warranty Li-ion batteries: 3-year limited warranty All other products: 5-year limited warranty.
NOTE:
The option of a 10-year limited warranty can only be applied during the actual purchase of the product.
