Description
| PRODUCT NAME | Victron SmartSolar MPPT Charge Controller 75/10 SCC075010060R | Victron SmartSolar MPPT Charge Controller 75/15 SCC075015060R |
| DESCRIPTIONS | The Victron SmartSolar MPPT Charge Controller 75V is available in two distinct model types, allowing you to choose the configuration that best suits your solar energy needs. This flexibility ensures that you get the most out of your solar system. | |
| FEATURES | >Bluetooth Smart built-in | |
| >VE.Direct | ||
| >Ultra-fast Maximum Power Point Tracking (MPPT) | ||
| >Load output | ||
| >Battery Life: intelligent battery management | ||
| >Programmable battery charge algorithm | ||
|
>Programming, real-time data and history display options |
||
SPECIFICATIONS
| PRODUCT NAME | Victron SmartSolar MPPT Charge Controller 75/10 SCC075010060R | Victron SmartSolar MPPT Charge Controller 75/15 SCC075015060R |
| SKU | SCC075010060R | SCC075015060R |
| Brands | Victron | |
| Product Category | Solar Charge Controllers | |
| GTIN (Global Trade Item Number) | 8719076040798 | 8719076040804 |
| Amps | 10A | 15A |
| Nominal PV Power | 12V - 145W | 24V - 290W | 12V - 220W | 24V - 440W |
| Efficiency | 98% | 98% (Peak) |
| Operating Temperature Range | -30 to +60°C (full rated output up to 40°C) | |
| Humidity | 95%, non-condensing | |
| Dimensions | 40 x 113 x 100 (D x W x H) | |
| Net Weight (kg) | 0.5 Kg | |
| Charge voltage 'absorption' | 14.4V / 28.8V (adjustable) | |
| Protection | Battery reverse polarity (fuse), Output short circuit and Over temperature | |
| Manufacturers Warranty | 5 Years | |
WARRANTY
Victron Energy warrants its products to be free from defects in workmanship and materials for a period of Batteries: 2-year limited warranty Li-ion batteries: 3-year limited warranty All other products: 5-year limited warranty.
NOTE:
The option of a 10-year limited warranty can only be applied during the actual purchase of the product.
