Victron SmartSolar MPPT 250/60 Solar Charge Controller Available in 2 Model Types

Model Type: 250/60 TR Bluetooth Charge Controller SCC125060221
Warranty Option: Standard 5 Years Warranty
Sale price$1,125.00


Product Name Victron SmartSolar MPPT 250/60 TR Bluetooth Charge Controller SCC125060221 Victron SmartSolar MPPT 250/60 MC4 Bluetooth Charge Controller SCC125060321
DESCRIPTIONS A solar charger gathers energy from your solar panels and stores it in your batteries. Using the latest, fastest technology, SmartSolar maximizes this energy harvest, driving it intelligently to achieve full charge in the shortest possible time. SmartSolar maintains battery health, extending its life.
FEATURES >Bluetooth Smart built-in: dongle not needed
  >Ultra-fast Maximum PowerPoint Tracking (MPPT)
  >Advanced Maximum PowerPoint Detection in case of partial shading conditions
  >Outstanding conversion efficiency
  >Flexible charge algorithm
  >Programming, real-time data, and history display options
  >Programmable relay
  >Optional: pluggable LCD display
  >Remote on-off
  >Extensive electronic protection
  >Internal  temperature sensor



SmartSolar Charge Controller MPPT 250/60
Battery Voltage 12 / 24 / 48V Auto Select(Software tool needed to select 36V)
Rated charge current 60A
Nominal PV power, 12V 1a,b) 860W
Nominal PV power, 24V 1a,b) 1720W
Nominal PV power, 48V 1a,b) 3440W
Max. PV short circuit current  2) 50A (max 30A per MC4 conn.)
Maximum PV opencircuit voltage 250V absolute maximum coldest conditions
245V start-up and operating maximum
Maximum efficiency 99%
Self-consumption Less than 35mA @ 12V / 20mA @ 48V
Charge voltage 'absorption' Default setting: 14,4 / 28,8 / 43,2 / 57,6V
(adjustable with: rotary switch, display, VE.Direct or Bluetooth)
Charge voltage 'float' Default setting: 13,8 / 27,6 / 41,4 / 55,2V
(adjustable: rotary switch, display, VE.Direct or Bluetooth)
Charge algorithm multi-stage adaptive
Temperature compensation -16 mV / -32 mV / -64 mV / °C
Protection Battery reverse polarity (fuse, not user accessible)
PV reverse polarity / Output short circuit / Over temperature
Operating temperature -30 to +60°C (full rated output up to 40°C)
Humidity 95%, non-condensing
Maximum altitude 5000m (full rated output up to 2000m)
Data communication port VE.Direct or Bluetooth
Remote on/off Yes (2 pole connector)
Programmable relay DPST
AC rating: 240VAC / 4A
DC rating: 4A up to 35VDC, 1A up to 60VDC
Parallel operation Yes (not synchronized)
Colour Blue (RAL 5012)
PV terminals 3) 35 mm² / AWG2 (Tr models)
Two sets of MC4 connectors (MC4 models 250/60 and 250/70)
Three sets of MC4 connectors (MC4 models 250/85 and 250/100)
Battery terminals 35mm² / AWG2
Protection category IP43 (electronic components), IP22 (connection area)
Weight 3 kg
Dimensions (h x w x d) in mm Tr models: 185 x 250 x 95
MC4 models: 215 x 250 x 95


Victron Energy warrants its products to be free from defects in workmanship and materials for a period of Batteries: 2-year limited warranty Li-ion batteries: 3-year limited warranty All other products: 5-year limited warranty.


The option of a 10-year limited warranty can only be applied during the actual purchase of the product.
