Victron Smart Solar MPPT 150/100-MC4 VE.Can Charge Controller SCC115110511, 5 Year Warranty. A solar charger gathers energy from your solar panels and stores it in your batteries. Using the latest, fastest technology, SmartSolar maximizes this energy-harvest, driving it intelligently to achieve full charge in the shortest possible time. SmartSolar maintains battery health, extending its life.
MPPT: Ultra Fast Maximum Power Point Tracking:
By constantly monitoring the voltage and current output of your solar (PV) panels, MPPT technology ensures that every drop of available power is rinsed out of your panels, and harvested for storage. The advantage of this is most noticeable when the sky is partially clouded, and light intensity is constantly changing.
Remote Monitoring and Control:
Remotely control and monitor the extensive features of your SmartSolar MPPT charger with built-in bluetooth by pairing it with your smartphone or other device via VictronConnect. If your installation is connected to the internet Victron Remote Management Portal (VRM) provides access to the full power of your MPPT, anytime, anywhere; both services are free to use. For remote installations - even when there is no internet connection or phone signal nearby - you may be able to monitor your MPPT by bluetooth-pairing with a LoRaWAN (long-range wide area network) device, available optionally.
Optional SmartSolar Control Display:
By adding the SmartSolar Control Display you will be able to check the status of your Charger and battery-storage at a glance. Simply plug it into the face of your MPPT charger to provide you with real-time monitoring and set-up capabilities.
Ultra-fast Maximum Power Point Tracking (MPPT):
Especially in case of a clouded sky, when light intensity is changing continuously, an ultra-fast MPPT controller will improve energy harvest by up to 30% compared to PWM charge controllers and by up to 10% compared to slower MPPT controllers.
Advanced Maximum Power Point Detection in case of partial shading conditions:
If partial shading occurs, two or more maximum power points may be present on the powervoltage curve. Conventional MPPTs tend to lock to a local MPP, which may not be the optimum MPP. The innovative SmartSolar algorithm will always maximize energy harvest by locking to the optimum MPP.
Outstanding conversion efficiency:
No cooling fan. Maximum efficiency exceeds 98%.
Flexible charge algorithm:
Fully programmable charge algorithm, and eight preprogrammed algorithms, selectable with a rotary switch (see manual for details).
Extensive electronic protection:
Over-temperature protection and power derating when temperature is high.
PV short circuit and PV reverse polarity protection.
PV reverse current protection.
Internal temperature sensor:
Compensates absorption and float charge voltage for temperature.
Bluetooth Smart built-in: dongle not needed:
The wireless solution to set-up, monitor and update the controller using Apple and Android smartphones, tablets or other devices.
For a wired data connection to a Color Control GX, other GX products, PC or other devices
To connect for example to a VE.BUS BMS.
Can be programmed (a.o. with a smartphone) to trip on an alarm, or other events.
Optional: pluggable LCD display:
Simply remove the rubber seal that protects the plug on the front of the controller, and plug-in the display.
|Model||SmartSolar MPPT 150/100-MC4|
|Float||Default setting: 13,8 / 27,6 / 41,4 / 55,2V (adjustable: rotary switch, display, VE.Direct or Bluetooth)|
|Equalize||Default setting: 16,2V / 32,4V / 48,6V / 64,8V (adjustable)|
|Voltage||12 / 24 / 48V Auto Select|
|Nominal PV Power||12V: 1450W | 24V: 2900W | 36V: 4350W | 48V: 5800W|
|Operating Temperature Range||-30 to +60°C (full rated output up to 40°C)|
|PV Short Circuit Current||70A (max 30A per MC4 conn.)|
|Dimensions (LxWxH mm)||Tr Model: 103 x 295 x 216 mm | MC4 Model: 103 x 295 x 246 mm|
|Charge voltage 'absorption'||Default setting: 14,4 / 28,8 / 43,2 / 57,6V (adjustable with: rotary switch, display, VE.Direct or Bluetooth)|
|Temperature Compensation||-16 mV / -32 mV / -64 mV / °C|
|Protection||Battery reverse polarity (fuse, not user accessible), PV reverse polarity, Output short circuit and Over temperature|
|Manufacturers Warranty||5 Years|
Victron Energy warrants its products to be free from defects in workmanship and materials for a period of Batteries: 2-year limited warranty Li-ion batteries: 3-year limited warranty All other products: 5-year limited warranty.
The option of a 10-year limited warranty can only be applied during the actual purchase of the product.
