Description
| Product Name | Victron Skylla-TG GMDSS 120-240V excl. Panel 24/30 SDTG2400302 | Victron Skylla-TG GMDSS 120-240V excl. Panel 24/50 SDTG2400504 |
| DESCRIPTIONS | Victron Skylla-TG GMDSS 120-240V excl. panel, 5-Year Warranty. The Victron Skylla-TG 24/30 and 24/50 GMDSS Chargers have been designed to provide all required monitoring and alarm data. Both the battery and the GMDSS system are connected directly to the charger. | |
| FEATURES | The Global Maritime Distress & Safety System (GMDSS) was developed by the International Maritime Organisation (IMO) to improve maritime distress and safety communications. | |
| The Skylla TG has proven itself to be an excellent battery charger and power supply for GMDSS applications. | ||
| Installation made easy: the Skylla GMDSS | ||
| No adjustments needed | ||
| Battery time to go | ||
| Perfect charger for any type of battery | ||
SPECIFICATIONS
| Product Name | Victron Skylla-TG GMDSS 120-240V excl. Panel 24/30 SDTG2400302 | Victron Skylla-TG GMDSS 120-240V excl. Panel 24/50 SDTG2400504 |
| SKU | SDTG2400302 | SDTG2400504 |
| Brand | Victron | |
| GTIN | 8719076025726 | 8719076025764 |
| Product Category | Battery Chargers | |
| Warranty Period | 5 Years | |
| Model | SDTG2400302 | SDTG2400504 |
| Protection category | IP21 | |
| Output System Voltage | 24V | |
| Dimensions | 485 x 250 x 147 mm (L x W x H) | |
| Charge voltage 'absorption' | 28.5 V | |
| Input Voltage | 90 - 265V AC | |
| Battery-connection | M8 bolts | |
| Output Current Rating (Amps) | 30A | 50A |
| Charge Voltage Float - Wet (25 degrees) | 26.5V | |
| Charge current | 30 (limited to 22 A at 110 V AC) | 50 A |
| Operating Temperature Range | -40 to +50°C (-40 - 122°F) | |
| Humidity | max 95% | |
| Net Weight (kg) | 6 Kg | |
WARRANTY
Victron Energy warrants its products to be free from defects in workmanship and materials for a period of Batteries: 2-year limited warranty Li-ion batteries: 3-year limited warranty All other products: 5-year limited warranty.
NOTE:
The option of a 10-year limited warranty can only be applied during the actual purchase of the product.
