Victron Skylla-TG GMDSS 120-240V excl. Panel 24/50 SDTG2400504


Warranty Option: Standard 5 Years Warranty
Price:
Sale price$2,310.00

Description

Victron Skylla-TG 24/50 GMDSS 120-240V excl. panel, 5 Year Warranty. The Victron Skylla-TG 24/30 and 24/50 GMDSS Chargers have been designed to provide all required monitoring and alarm data. Both the battery and the GMDSS system are connected directly to the charger. Data and alarms are displayed on a digital panel (VE.Net GMDSS panel, to be ordered separately). A standard eight wire UTP cable connects the charger to the panel.

FEATURES

GMDSS:
The Global Maritime Distress & Safety System (GMDSS) was developed by the International Maritime Organization (IMO) to improve maritime distress and safety communications.

Power supply:
The Skylla TG has proven itself to be an excellent battery charger and power supply for GMDSS applications. However, when using a standard Skylla Charger, additional equipment is needed to perform the monitoring and alarm functions required for GMDSS.

Installation made easy: the Skylla GMDSS:
The Victron Skylla GMDSS Charger has been designed to provide all required monitoring and alarm data. Both the battery and the GMDSS system are connected directly to the charger. Data and alarms are displayed on a digital panel (VE.Net GMDSS panel, to be ordered separately). A standard eight wire UTP-cable connects the charger to the panel.

No adjustments needed:
The whole system is ‘click and go’: the panels are pre-programmed for GMDSS functionality. A simple, intuitive the menu allows changing settings if required.

Battery time to go:
The Skylla GMDSS charger has a built-in battery controller. The capacity of the battery is fully monitored so the panel can even indicate the ’time to go’ in case of a power supply blackout.

Perfect charger for any type of battery:
Charge voltage can be precisely adjusted to suit any VRLA or flooded battery system.

SPECIFICATIONS

Product Name Victron Skylla-TG GMDSS 120-240V excl. Panel 24/50 SDTG2400504
SKU SDTG2400504
GTIN (Global Trade Item Number) 8719076025764
Brands Victron
Product Category Battery Chargers
Model SDTG2400504
Output Current Rating (Amps) 50.0 Amps
Operating Temperature Range -40 to +50°C (-40 - 122°F)
Humidity max 95%
Output System Voltage 24V
Charge current 50 A
Dimensions 485 x 250 x 147 mm (L x W x H)
Net Weight (kg) 6.0 Kg
Charge voltage 'absorption' 28.5V
Charge Voltage Float - Wet (25 degrees)** 26.5V
Protection category IP 21
Battery-connection M8 bolts
Input Voltage 90 - 265V AC
Can be used as power supply Yes
Manufacturers Warranty 5 Years



WARRANTY

Victron Energy warrants its products to be free from defects in workmanship and materials for a period of Batteries: 2-year limited warranty Li-ion batteries: 3-year limited warranty All other products: 5-year limited warranty.

NOTE:

The option of a 10-year limited warranty can only be applied during the actual purchase of the product.
