Victron Phoenix Smart IP43 24/25 Battery Charger Available in 2 Model Types


Model Type: (1+1) 230V PSC242551085
Warranty Option: Standard 5 Years Warranty
Price:
Sale price$800.00

Description

Product Name Victron Phoenix Smart IP43 24/25 Battery Charger 1+1 230V PSC242551085 Victron Phoenix Smart IP43 24/25 Battery Charger (3) 230V PSC242553085
DESCRIPTIONS Phoenix Smart (1+1): two outputs to charge 2 battery banks
The second output, limited to approximately 3A and with a slightly lower output voltage, is intended to top up a starter battery.
Phoenix Smart (3): three full current outputs to charge 3 battery banks
Each output can supply the full rated output current. But the total of the 3 outputs combined can never exceed the current rating of the charger.
FEATURES Bluetooth Smart enabled
  Automatic voltage compensation
  Adaptive 5-stage charge algorithm: bulk – absorption – recondition – float – storage
  The right amount of charge: variable absorption time
  Preventing damage due to excessive gassing: the BatterySafe mode
  Less maintenance and aging when the battery is not in use: the Storage Mode
  Also charges Li-ion (LiFePO₄) batteries
  Fully programmable charge algorithm
  Remote on-off
  VE.Direct interface
  Programmable relay



SPECIFICATIONS

Product Name Victron Phoenix Smart IP43 24/25 Battery Charger 1+1 230V PSC242551085 Victron Phoenix Smart IP43 24/25 Battery Charger (3) 230V PSC242553085
SKU PSC242551085 PSC242553085
GTIN (Global Trade Item Number) 8719076041641 8719076041658
Brands Victron
Product Category Battery Chargers
Model PSC242551085 PSC242553085
Output Current Rating (Amps) 25.0 Amps
Efficiency 94%
Output System Voltage 24V
Operating Temperature Range  -20 to 60°C (0 - 140°F)
AC Input Connection IEC 320 C14 inlet with retainer clip (AC cord with country-specific plug must be ordered separately)
Humidity Max 95%
Output System Voltage 24V
Charge current 25 A
Dimensions 180 x 249 x 100 mm (L x W x H)
Net Weight (kg) 3.5 Kg
Charge Algorithm 5 stage adaptive
Charge voltage 'absorption' Normal: 28,8V High: 29,4V Li-ion: 28,4V
Charge Voltage Float - Wet (25 degrees)** Normal: 27,6V High: 27,6V Li-ion: 27,0V
Charge voltage 'storage' Normal: 26,4V High: 26,4V Li-ion: 27,0V
Protection category IP43 (electronic components), IP22 (connection area)
Battery-connection Screw terminals 16 mm² (AWG6)
Input Voltage 230 VAC (range: 210 – 250 V
Manufacturers Warranty 5 Years

WARRANTY

Victron Energy warrants its products to be free from defects in workmanship and materials for a period of Batteries: 2-year limited warranty Li-ion batteries: 3-year limited warranty All other products: 5-year limited warranty.

NOTE:

The option of a 10-year limited warranty can only be applied during the actual purchase of the product.
