Victron Phoenix Inverter 48/800 120V VE.Direct Nema 5-15R PIN481800500

Sale price$550.00


Victron Phoenix Pure Sine Wave Inverter 48V / 800VA VE.Direct AU/NZ, 5-Year Warranty. Inverters allow you to power domestic equipment - requiring 230V/120V AC - using 'leisure' or 'automotive' batteries rated at 12V, 24V, or 48V DC.


Proven reliability:

The full bridge plus toroidal transformer topology has proven its reliability over many years.
The inverters are short-circuit proof and protected against overheating, whether due to overload or high ambient temperature.

High start-up power:

Needed to start loads such as power converters for LED lamps, halogen lamps, or electric tools.

ECO mode:

When in ECO mode, the inverter will switch to standby when the load decreases below a preset value (min load: 15W). Once on standby, the inverter will switch on for a short period (adjustable, default: every 2,5 seconds). If the load exceeds a preset level, the inverter will remain on.

Remote on/off:

A remote on/off switch can be connected to a two-pole connector, or between battery plus and the left-hand contact of the two-pole connector.

To transfer the load to another AC source: the automatic transfer switch

For our low-power inverters, we recommend our Filax Automatic Transfer Switch. The Filax features a very short switchover time (less than 20 milliseconds) so that computers and other electronic equipment will continue to operate without disruption.

Fully configurable:

  • Low battery voltage alarm trip and reset levels
  • Low battery voltage cut-off and restart levels
  • Dynamic cut-off: load-dependent cut-off level
  • Output voltage:210 - 245V
  • Frequency: 50 Hz or 60 Hz
  • ECO mode on/off and ECO mode sense level


  • In- and output voltage, % load, and alarms


  • Cont. power at 25°C: 800VA
  • Cont. power at 25°C / 40°C: 650 / 560W
  • Peak power: 1500W
  • Output AC voltage / frequency (adjustable): 230VAC or 120VAC +/- 3% ; 50Hz or 60Hz +/- 0,1%
  • Input voltage range: 36,8 - 62,0V
  • DC low shut down (adjustable): 37,2V
  • Dynamic (load dependent) DC low shut down (fully configurable): Dynamic cut-off, see
  • DC low restart and alarm (adjustable): 43,6V
  • Battery charged detect (adjustable): 56,0V
  • Max. efficiency: 91%
  • Zero-load power: 9,5W
  • Default zero-load power in ECO mode (default retry interval: 2,5 s, adjustable): 3,0
  • ECO mode stop and start power setting: Adjustable
  • Protection: a - f
  • Operating temperature range: -40 to +65°C (fan assisted cooling) ; Derate 1,25% per °C above 40°C
  • Humidity (non-condensing): max 95%


Victron Energy warrants its products to be free from defects in workmanship and materials for a period of Batteries: 2-year limited warranty Li-ion batteries: 3-year limited warranty All other products: 5-year limited warranty.
