Description
| Product Name | Victron Phoenix Inverter 48/5000VA Compact PIN485020000 | Victron Phoenix Inverter 48/5000VA 230V Smart PIN482500000 |
| DESCRIPTIONS | The Phoenix Inverter Compact is a pure sine wave inverter with a high efficiency. It is developed for professional duty and suitable for the wide range of applications. The Phoenix Inverters Compact is available from 1200VA up to 2000VA in 12V or 24V. | The Phoenix Inverter Smart is an efficient and reliable inverter. Built on Victrons' proven and field tested Phoenix inverter platform, it now comes with a new slimmer design and full metal casing. |
| FEATURES | >SinusMax - Superior engineering | >Bluetooth built-in: fully configurable with a tablet or smartphone |
| >Extra start-up power | >VE.Direct communication port | |
| >Virtually unlimited power thanks to parallel and 3-phase operation capability | >Proven reliability | |
| >To transfer the load to another AC source: the automatic transfer switch | >High start-up power | |
| >Computer interface | >Remote on/off | |
| >New applications of high power inverters |
SPECIFICATIONS
| Product Name | Victron Phoenix Inverter 48/5000VA Compact PIN485020000 | Victron Phoenix Inverter 48/5000VA 230V Smart PIN482500000 |
| SKU | PIN485020000 | PIN482500000 |
| GTIN (Global Trade Item Number) | 8719076023883 | 8719076047940 |
| Brands | Victron | Victron |
| Product Category | Power Inverters | Power Inverters |
| Model | PIN485020000 | PIN482500000 |
| Wattage | 4000W | 4000W |
| DC Input Voltage | 38 – 66V | 37.2 - 68V |
| Output | 230 VAC ±2% Frequency: 50 Hz ± 0,1% (1) | 230VAC ±2% 50 Hz or 60Hz ± 0,1% (1) |
| Peak Power | 10000 | 10000VA |
| Humidity | Max 95% | Max 95% (non-condensing) |
| Dimensions | 444 x 328 x 240 (H x W x D) | 555 x 295 x 160mm (H x W x D) |
| Battery-connection | 2+2 M8 bolts | 2+2 M8 bolts |
| Net Weight (kg) | 30 | 29 |
WARRANTY
Victron Energy warrants its products to be free from defects in workmanship and materials for a period of Batteries: 2-year limited warranty Li-ion batteries: 3-year limited warranty All other products: 5-year limited warranty.
NOTE:
The option of a 10-year limited warranty can only be applied during the actual purchase of the product.
