Victron Phoenix Inverter 12V/250VA VE.Direct AU/NZ PIN122510300


Price:
Sale price$180.00

Description

Victron Phoenix Inverter 12V / 250VA VE.Direct AU/NZ, 5-Year Warranty. Inverters allow you to power domestic equipment - requiring 230V/120V AC - using 'leisure' or 'automotive' batteries rated at 12V, 24V, or 48V DC.

VE.Direct communication port:

  • The VE. Direct port can be connected to:
    • A computer (VE.Direct to USB interface cable needed)
    • Apple and Android smartphones, tablets, MacBook, and other devices (VE.Direct Bluetooth Smart dongle needed)
  • Fully configurable:
    • Low battery voltage alarm trip and reset levels
    • Low battery voltage cut-off and restart levels
    • Dynamic cut-off: load-dependent cut-off level
    • Output voltage 210 - 245V
    • Frequency 50 Hz or 60 Hz
    • ECO mode on/off and ECO mode sense level
  • Monitoring:
    • In- and output voltage, % load, and alarms

FEATURES

Proven reliability:

The full bridge plus toroidal transformer topology has proven its reliability over many years. The inverters are short-circuit proof and protected against overheating, whether due to overload or high ambient temperature.

High start-up power:

Needed to start loads such as power converters for LED lamps, halogen lamps, or electric tools.

ECO mode:

When in ECO mode, the inverter will switch to standby when the load decreases below a preset value (min load: 15W). Once on standby, the inverter will switch on for a short period (adjustable, default: every 2,5 seconds). If the load exceeds a preset level, the inverter will remain on.

Remote on/off:

A remote on/off switch can be connected to a two-pole connector, or between battery plus and the left-hand contact of the two-pole connector.

LED diagnosis:

Please see the manual for a description.

To transfer the load to another AC source: the automatic transfer switch:

For our low-power inverters, we recommend our Filax Automatic Transfer Switch. The Filax features a very short switchover time (less than 20 milliseconds) so that computers and other electronic equipment will continue to operate without disruption.

SPECIFICATIONS

Product Name

Victron Phoenix Inverter 12V/250VA VE.Direct AU/NZ PIN122510300

SKU PIN122510300
GTIN (Global Trade Item Number) 8719076033950
Brands Victron
Product Category Power Inverters
Model PIN122510300
Wattage 200W
Peak Power 400W
Output Voltage and Frequency 230VAC or 120VAC +/- 3% | 50Hz or 60Hz +/- 0,1%
Protection a) output short circuit, b) overload, c) battery voltage too high, d) battery voltage too low, e) temperature too high, f) DC ripple too high
Input Voltage 9,2 - 17V
Operating Temperature Range -40 to +65°C (fan-assisted cooling)
Humidity Max 95%
Dimensions 260 x 165 x 86
Battery-connection Screw terminals
Protection category IP 21
Efficiency 87%
Net Weight (kg) 2.4 Kg

WARRANTY

Victron Energy warrants its products to be free from defects in workmanship and materials for a period of Batteries: 2-year limited warranty Li-ion batteries: 3-year limited warranty All other products: 5-year limited warranty.
