Victron Phoenix Inverter 12V/800VA VE.Direct AU/NZ PIN121801300

Warranty Option: Standard 5 Years Warranty
Sale price$479.00


Victron Phoenix Inverter 12V / 800VA VE.Direct AU/NZ, 5-Year Warranty. Inverters allow you to power domestic equipment - requiring 230V/120V AC - using 'leisure' or 'automotive' batteries rated at 12V, 24V, or 48V DC.

VE.Direct communication port

  • The VE.Direct port can be connected to:
    • A computer (VE.Direct to USB interface cable needed)
    • Apple and Android smartphones, tablets, MacBook and other devices (VE.Direct Bluetooth Smart dongle needed)
  • Fully configurable:
    • Low battery voltage alarm trip and reset levels
    • Low battery voltage cut-off and restart levels
    • Dynamic cut-off: load-dependent cut-off level
    • Output voltage 210 - 245V
    • Frequency 50 Hz or 60 Hz
    • ECO mode on/off and ECO mode sense level
  • Monitoring:
    • In- and output voltage, % load, and alarms


Proven reliability:

The full bridge plus toroidal transformer topology has proven its reliability over many years. The inverters are short-circuit proof and protected against overheating, whether due to overload or high ambient temperature.

High start-up power:

Needed to start loads such as power converters for LED lamps, halogen lamps, or electric tools.

ECO mode:

When in ECO mode, the inverter will switch to standby when the load decreases below a preset value (min load: 15W). Once on standby the inverter will switch on for a short period (adjustable, default: every 2,5 seconds). If the load exceeds a preset level, the inverter will remain on.

Remote on/off:

A remote on/off switch can be connected to a two-pole connector, or between battery plus and the left-hand contact of the two-pole connector.

LED diagnosis:

Please see the manual for a description.

To transfer the load to another AC source: the automatic transfer switch:

For our low-power inverters, we recommend our Filax Automatic Transfer Switch. The Filax features a very short switchover time (less than 20 milliseconds) so that computers and other electronic equipment will continue to operate without disruption.


Product Name Victron Phoenix Inverter 12V/800VA VE.Direct AU/NZ PIN121801300
SKU PIN121801300
GTIN (Global Trade Item Number) 8719076055051
Brands Victron
Product Category Power Inverters
Model PIN128010100
Wattage 650W
Peak Power 1500
Output Voltage and Frequency 110 VAC or 230 VAC +/- 3% | 50 Hz or 60 Hz +/- 0,1%
Protection a) output short circuit, b) overload, c) battery voltage too high, d) battery voltage too low, e) temperature too high
Input Voltage 9,2 - 17V
Battery Low Alarm Protection 10.9V
Battery Low Shutdown Protection 9.3V
Operating Temperature Range -40 to +50°C (fan-assisted cooling)
Humidity max 95%
Dimensions 305 x 216 x 105
Battery-connection Screw terminals
Protection category IP 21
Efficiency 90%
Net Weight (kg) 5.5 Kg


Victron Energy warrants its products to be free from defects in workmanship and materials for a period of Batteries: 2-year limited warranty Li-ion batteries: 3-year limited warranty All other products: 5-year limited warranty.


The option of a 10-year limited warranty can only be applied during the actual purchase of the product.
