Victron Phoenix Inverter 12/3000 Available in 2 Model Types

Model Type: 12V/3000VA Pure Sine Wave PIN123020000
Warranty Option: Standard 5 Years Warranty
Sale price$2,170.00


Product Name Victron Phoenix Pure Sine Wave Inverter 12V/3000VA (PIN123020000) Victron Phoenix Inverter 12V/3000VA 230V Smart (PIN122300000)
PRODUCT DESCRIPTIONS Pure sine wave output, high peak power, and high efficiency. Combined high-frequency and line-frequency technologies ensure the best of both worlds. The Phoenix Inverter Smart is an efficient and reliable inverter. Built on our proven and field-tested Phoenix inverter platform, it now comes with a new slimmer design and full metal casing. Models are available in 1600VA, 2000VA, and 3000VA for 12, 24, or 48V systems.
FEATURES > SinusMax - Superior engineering > In- and output voltage, load, and alarms VE.Direct communication port
  > Parallel and 3-phase operation capability > Proven reliability
  > Extra start-up power > High start-up power
  > Virtually unlimited power thanks to parallel 3-phase and split-phase operation capability > ECO mode
  > To transfer the load to another AC source: the automatic transfer switch > Remote on/off
  > Computer interface > LED diagnosis
  > New applications of high-power inverters > To transfer the load to another AC source: the automatic transfer switch



MODEL Victron Phoenix Inverter 12V/3000VA Victron Phoenix Inverter 12V/3000VA Smart
SKU PIN123020000 PIN122300000
GTIN (Global Trade Item Number) 8719076023579 8719076047360
Brands Victron Victron
Product Category Power Inverters Power Inverters
Model PIN123020000 PIN122300000
Wattage 2400W 2400W
Peak Power 6000 6000VA
Output Voltage and Frequency Output 230VAC +/- 2% 50Hz +/- 0.1% 230VAC ±2% 50 Hz or 60Hz ± 0,1% (1)
Input Voltage 9,5 – 17V 9.3 - 17V
Operating Temperature Range -40 to +65ºC (-40 - 150°F) -40 to +65ºC (fan-assisted cooling)
Humidity max 95% Max 95% (non-condensing)
Dimensions 218 x 258 x 362 533 mm x 285 mm x 150 mm (H x W x D)
Battery-connection 2+2 M8 bolts 2+2 M8 bolts
Protection category IP 21 IP21
Efficiency 93% 95%
Net Weight (kg) 18.0 Kg 19.0 Kg


Victron Energy warrants its products to be free from defects in workmanship and materials for a period of Batteries: 2-year limited warranty Li-ion batteries: 3-year limited warranty All other products: 5-year limited warranty.


The option of a 10-year limited warranty can only be applied during the actual purchase of the product.
