Description
| Product Name | Victron Orion-Tr Smart Non-isolated Charger 24/12 30A 360W ORI241236140 | Victron Orion-Tr Smart Non-isolated Charger 24/24 17A 400W ORI242440140 |
| DESCRIPTIONS | The Orion-Tr Smart DC-DC charger is a professional DC to DC adaptive 3-stage charger with built-in Bluetooth. For use in dual battery systems in vehicles or on boats where the alternator and the start battery are used to charge the service battery. | |
| FEATURES | >Bluetooth Smart enabled | |
| >Fully programmable | ||
| >Adaptive 3-stage charge algorithm: bulk – absorption – float | ||
| >Remote on-off | ||
| >All models are short circuit proof and can be paralleled to increase output current | ||
| >High temperature protected | ||
| >IP43 protection | ||
| >Screw terminals | ||
| >Isolated DC to DC Chargers Vs Non-Isolated DC to DC Chargers | ||
| >DC to DC Charger without solar regulator | ||
SPECIFICATIONS
| Product Name | Victron Orion-Tr Smart Non-isolated Charger 24/12-30A 360W ORI241236140 | Victron Orion-Tr Smart Non-isolated Charger 24/24 17A 400W ORI242440140 |
| SKU | ORI241236140 | ORI242440140 |
| GTIN (Global Trade Item Number) | 8719076048978 | 8719076048985 |
| Brands | Victron | |
| Product Category | Battery Chargers | |
| Output Current Rating (Amps) | 30.0 Amps | 17.0 Amps |
| DC Input Voltage | 20-35V | |
| DC Output Voltage | 12,2V | 24,2V |
| Standby Current | Less than 1 mA | |
| Efficiency | 88% | 89% |
| Operating Temperature Range | -20 to +55°C (derate 3% per °C above 40°C) | |
| Humidity | Max. 95% non-condensing | |
| Output System Voltage | 24V | |
| Short Circuit Current Isc(A) | 60A | 40A |
| Dimensions | 130 x 186 x 80 mm (L x W x H) | |
| Net Weight (kg) | 1.8 Kg | |
| Under Voltage Shutdown | 14V | |
| Maximum Charge Current | 45A | 25A |
| No load power consumption | <100 mA | <80 mA |
| Manufacturers Warranty | 5 Years | |
WARRANTY
Victron Energy warrants its products to be free from defects in workmanship and materials for a period of Batteries: 2-year limited warranty Li-ion batteries: 3-year limited warranty All other products: 5-year limited warranty.
NOTE:
The option of a 10-year limited warranty can only be applied during the actual purchase of the product.
