Description
This is a step-down voltage converter with a 24 Volt input and a 12 Volt output. Water-resistant to IP 67. The first digit of the IP rating refers to dust and 6 means it is dustproof. The second digit of the IP rating refers to water and 7 means protected against the effects of immersion in water to a depth between 15 cm and 1 meter. This DC-DC converter is completely encapsulated: waterproof, shockproof, and ignition protected. Water, oil, or dirt will not damage the Orion IP67 DC-DC Converter. The casing is made of cast aluminum and the electronics are moulded in resin. Available in 3 models: Orion IP67 24/12-5, Orion IP67 24/12-10, and Orion IP67 24/12-20
FEATURES
- 5 Amps output rating - 60 Watts
-
Input Voltage Range 15-40 Volts DC
-
Output voltage 12 Volts +/- 3%
- Efficiency 93%
- Dimensions 25 x 43 x 20 mm
- Non-Isolated (input and output negative is shared)
- Protected against overheating - can be used in a hot environment such as a machine room
- Extra long 1.8m cables included
- Now with a five-year manufacturers warranty
SPECIFICATIONS
| SKU: ORI241205260 |
| Brand: Victron |
| GTIN: 8719076048428 |
| Product Category: Converters |
| Warranty Period: 5 Years |
| Net Weight (kg): 0.05 |
| Rating (A): 5A |
| DC Output Voltage: 12V +/- 3% |
| Dimensions: 20 x 43 x 25 |
| Short circuit protection: Yes |
| Protection category: IP67 |
| DC Input Voltage: 15-40VDC |
| Overload protection: Hiccup mode, recovers automatically after the fault condition is removed |
| Efficiency: 93% |
| Operating Temperature Range: -20 to +70°C (full rated output up to 40°C) |
WARRANTY
Victron Energy warrants its products to be free from defects in workmanship and materials for a period of Batteries: 2-year limited warranty Li-ion batteries: 3-year limited warranty All other products: 5-year limited warranty.
