Victron Orion IP67 24/12V 10A DC to DC Converter Non-Isolated 120W, 5-Year Warranty. Completely encapsulated: waterproof, shockproof, and ignition protected. Water, oil, or dirt will not damage the Orion IP67 DC-DC Converter. The casing is made of cast aluminum and the electronics are molded in resin.
Completely encapsulated: waterproof, shockproof, and ignition protected:
Water, oil or dirt will not damage the Orion IP67 DC-DC Converter. The casing is made of cast aluminum and the electronics are molded in resin.
Extra-long input and output cables:
Thanks to the cables of 1.8 meters in length, intermediate cable interconnections to increase length even more will in most cases not be needed. This is an important reliability-increasing feature in an area where an IP67 protection grade is needed.
Wide input voltage range:
With a 15 to 40 Volts input range, a stable output is ensured during surges or sags due to other equipment connected to the same battery.
Protected against overheating:
It can be used in a hot environment such as a machine room.
|Product Category: Converters|
|Warranty Period: 5 Years|
|Short circuit protection: Yes|
|Protection category: IP67|
|DC Input Voltage: 15-40VDC|
|Dimensions: 32 x 74 x 74|
|Overload protection: Hiccup mode, recovers automatically after the fault condition is removed|
|Operating Temperature Range: -20 to +70°C (full rated output up to 40°C)|
|Net Weight (kg): 0.3|
|Rating (A): 10A|
|DC Output Voltage: 12V +/- 3%|
Victron Energy warrants its products to be free from defects in workmanship and materials for a period of Batteries: 2-year limited warranty Li-ion batteries: 3-year limited warranty All other products: 5-year limited warranty.
