Description
| Product Name | Victron Orion 12/24V DC-DC Converter Non Isolated 8A ORI122408020 | Victron Orion 12/24V DC-DC Converter Non Isolated 10A ORI122410020 | Victron Orion 12/24V DC-DC Converter Non Isolated 20A ORI122420020 |
| DESCRIPTIONS | The remote on-off eliminates the need for a high-current switch in the input wiring. The remote on-off can be operated with a low-power switch or by the engine run/stop switch (see manual). | ||
| FEATURES | Remote on-off connector | ||
| All models with adjustable output can also be used as battery chargers | |||
| All models with adjustable output can be paralleled to increase the output current | |||
SPECIFICATIONS
| Product Name | Victron Orion 12/24V DC-DC Converter Non Isolated 8A ORI122408020 | Victron Orion 12/24V DC-DC Converter Non Isolated 10A ORI122410020 | Victron Orion 12/24V DC-DC Converter Non Isolated 20A ORI122420020 |
| SKU: | ORI122408020 | ORI122410020 | ORI122420020 |
| Brand: | Victron | ||
| GTIN: | 8719076022732 | 8719076022749 | 8719076022763 |
| Product Category: | Converters | ||
| Warranty Period: | 5 Years | ||
| Net Weight (kg): | 0.4 | 0.9 | |
| Rating (A): | 8A | 10A | 20A |
| DC Output Voltage: | 24V | Adjustable 20-30V F set 26,4V | |
| Dimensions: | 115 x 90 x 45 | 125 x 90 x 45 | 195 x 88 x 65 |
| DC Input Voltage: | 9-18V | ||
| Efficiency: | 95% | 93% | |
| Operating Temperature Range: | -20 to +55°C | ||
WARRANTY
Victron Energy warrants its products to be free from defects in workmanship and materials for a period of Batteries: 2-year limited warranty Li-ion batteries: 3-year limited warranty All other products: 5-year limited warranty.
NOTE:
The option of a 10-year limited warranty can only be applied during the actual purchase of the product.
