Victron MultiPlus Inverter Charger 12/2000/80-32 PMP122200000

Warranty Option: Standard 5 Years Warranty
Sale price$1,710.00


Compatible with all batteries including Lithium.


The MultiPlus is an Inverter and Charger combination supporting easy installation by way of the Victron MK3-USB interface cable, including the following features:
  • True sine wave inverter
  • Adaptive charging
  • Hybrid PowerAssist
  • PowerControl
  • Multiple system integration
Multifunctional, with intelligent power management
The MultiPlus is a powerful true sine wave inverter, a sophisticated battery charger that features adaptive charge technology, and a high-speed AC transfer switch in a single compact enclosure.

Parallel operation and three phase capability
Up to six Multis can operate in parallel to achieve higher power output. In addition to parallel connection, three units can be configured for three-phase output.

PowerControl - Dealing with limited generator, shore side or grid power
With the Multi Control Panel a maximum generator or shore current can be set.

PowerAssist - Boosting the capacity of shore or generator power
This feature takes the principle of PowerControl to a further dimension. It allows the MultiPlus to supplement the capacity of the alternative source.

Four stage adaptive charger and dual bank battery charging
The main output provides a powerful charge to the battery system by means of advanced ‘adaptive charge’ software. The software fine-tunes the three-stage automatic process to suit the condition of the battery, and adds a fourth stage for long periods of float charging. The adaptive charge process is described in more detail on the Phoenix Charger datasheet and on our website, under Technical Information.

High start-up power
Needed to start high inrush loads such as power converters for LED lamps, halogen lamps or electric tools.

Search Mode
When Search Mode is ‘on’, the power consumption of the inverter in no-load operation is decreased by approx. 70%. In this mode the Multi, when operating in inverter mode, is switched off in case of no load or very low load, and switches on every two seconds for a short period.

Programmable relay
By default, the programmable relay is set as an alarm relay, i.e. the relay will de-energise in the event of an alarm or a pre-alarm (inverter almost too hot, ripple on the input almost too high, battery voltage almost too low).

Remote on / off / charger on
Three pole connector to mount an external remote if required.

Remote configuring and monitoring
Install a Cerbo GX or other GX product to connect to the internet. Operational data can be stored and displayed on Victrons Free VRM (Victron Remote Management) website, free of charge. When connected to the internet, systems can be accessed remotely, and settings can be changed.


MultiPlus 12/2000/80
PowerControl / PowerAssist YES
Three Phase and parallel operation YES
Transfer switch 35A
Input voltage range 9.5 - 17V
Output Output voltage: 230VAC ± 2%        Frequency: 50Hz ± 0,1%   (1)
Cont. output power at 25°C     (3) 2000VA
Cont. output power at 25°C 1600W
Cont. output power at 40°C 1400W
Cont. output power at 65°C 1000W
Peak power 3500 W
Maximum efficiency 93%
Zero-load power 10W
Zero-load power in search mode 3W
AC Input Input voltage range: 187-265 VAC                Input frequency: 45 –65 Hz
Charge voltage 'absorption' 14.4V
Charge voltage 'float' 13.8V
Storage mode 13.2V
Charge current house battery    (4) 80A
Charge current starter battery 1A
Battery temperature sensor YES
Programmable relay   (5) YES
Protection Output short circuit
Battery voltage too high
Battery voltage too low
Temperature too high
230VAC on inverter output
Input voltage ripple too high
VE.Bus communication port For parallel and three phase operation, remote monitoring and system integration
Remote on-off On/Off
DIP switches  Battery charge voltage / search mode
Internal DC fuse NO
Common Characteristics Operating temp. range: -40 to +65°C (fan assisted cooling)Humidity (non-condensing): max 95%
Common Characteristics Material & Colour: Steel(RAL 5012)  /  Protection Level: IP22
Battery-connection M8 Bolts
230V AC-connection Screw
Weight 13.5KG
Dimensions (h x w x d) 500 x 225 x 135 mm
Safety EN-IEC 60335-1, EN-IEC 60335-2-29, EN 62109-1
Emission Immunity EN 55014-1, EN 55014-2, EN-IEC 61000-3-2, EN-IEC 61000-3-3, IEC 61000-6-1, IEC 61000-6-2, IEC 61000-6-3
Automotive Directive ECE R10-5
  1) Can be adjusted to 60Hz and to 240V
3) Non-linear load, crest factor 3:1
4) At 25°C ambient
5) Programmable relay which can be set for:
general alarm, DC under voltage or generator start/stop signal function
AC rating: 230V/4A
DC rating: 4A up to 35VDC, 1A up to 60VDC


Victron Energy warrants its products to be free from defects in workmanship and materials for a period of: Batteries: 2-year limited warranty Li-ion batteries: 3-year limited warranty All other products: 5-year limited warranty.


The option of a 10-year limited warranty can only be applied during the actual purchase of the product.
