Victron MultiPlus-II Inverter Charger 48/5000/70-50 Available in 2 Model Types

Model Type: 48/5000/70-50 PMP482505010
Warranty Option: Standard 5 Years Warranty
Sale price$2,530.00


Product Name Victron MultiPlus-II Inverter Charger 48/5000/70-50 PMP482505010 Victron MultiPlus-II Inverter Charger 48/5000/70-50 GX PMP482506000
DESCRIPTIONS The MultiPlus-II combines the functions of the MultiPlus and the MultiGrid. It has all the features of the MultiPlus, plus an external current transformer option to implement PowerControl and PowerAssist and to optimize self-consumption with external current sensing (max. 32A). It also has all the features of the MultiGrid with built-in anti-islanding and an increasingly long list of country approvals. An Inverter/Charger with device networking built-in, the MultiPlus-II GX communicates with a solar charger, batteries, and other devices to control a grid-connected, off-grid, or remote power installation. Capable of parallel operation for increased power output, or battery charge-rates, the MultiPlus-II GX can also be configured for a three-phase supply. A host of advanced features - such as uninterrupted power supply, setting load limits, and supplementing limited grid-power availability with battery power - can all be controlled straight from your phone or smart device. Remote monitoring is also possible.
FEATURES >PowerAssist >Inverter/charger with GX inside
  >ESS: Energy Storage Systems >A MultiPlus-II with LCD and GX functionality
  >Uninterrupted AC power (UPS function) >Display and Wi-Fi
  >Remote Monitoring and Control GX device:
The integrated GX device includes:
A VE.Can interface. This can be used to connect to Victron VE.Can devices (eg VE.Can MPPTs), or the port can be reconfigured via the Remote Console for use with a compatible CAN-bus Li-ion Battery.
A USB port.
An Ethernet port.
A VE.Direct port.
  >A MultiPlus, plus ESS (Energy Storage System) functionality Applications:

The MultiPlus-II GX is intended for applications where additional interfacing with other products and/or remote monitoring is required, such as on-grid or off-grid energy storage systems and certain mobile applications.
  >PowerControl and PowerAssist - Boosting the capacity of the grid or a generator >Parallel and three-phase operation
  >Solar energy: AC power available even during a grid failure
  >Two AC Outputs
  >Virtually unlimited power thanks to parallel and three phase operation
  >On-site system configuring, monitoring and control
  >Remote configuring and monitoring



Product Name Victron MultiPlus-II Inverter Charger 48/5000/70-50 PMP482505010 Victron MultiPlus-II Inverter Charger 48/5000/70-50 GX PMP482506000
SKU PMP482505010 PMP482506000
GTIN (Global Trade Item Number) 8719076047599 8719076048824
Brands Victron
Product Category Power Inverter Chargers
Model 8719076047599 8719076048824
Product Type Inverter and charger in one package
Output Current Rating (Amps) 70.0 Amps
Wattage 4000W
Peak Power 9000W
Output Voltage and Frequency 230 Vac ± 2% / 50 Hz ± 0.1%
Output Power 4000W (continuous output power at 25­­°C) | 3700W (continuous output power at 40­­°C) | 3000W (continuous output power at 65­­°C)
Input Voltage 38-66V
Operating Temperature Range  -40 to +65°C
AC Input 187-265VAC | 45-65Hz
Inverter Output Continuous Watts 4000W (continuous output power at 25­­°C)
Charge voltage 'absorption' 57.6V
Charge Voltage Float - Wet (25 degrees)** 55.2V
Charge voltage 'storage' 52.8V
Inverter Output Nominal Efficiency 96% (maximum)
No load power consumption 18W | 2W in search mode
Product Dimensions (mm) LxWxH 320 x 141 x 560 148 x 323 x 565
Net Weight (kg) 29 30


Victron Energy warrants its products to be free from defects in workmanship and materials for a period of Batteries: 2-year limited warranty Li-ion batteries: 3-year limited warranty All other products: 5-year limited warranty.


The option of a 10-year limited warranty can only be applied during the actual purchase of the product.
