The inverter RS Smart is a powerful 48 VDC, 6 kVAC inverter. It features a modern design and high-frequency technology, weighing only 11kg and has excellent efficiency, low standby power, and very quiet operation.
The inverter is equipped with a display to read out battery and inverter details. These parameters can also be read out via Bluetooth by the VictronConnect app. In addition to this, the inverter has a VE Can Port, for connection to a GX device for system monitoring.
Lightweight, efficient and quiet
Thanks to high-frequency technology and a new design this powerful inverter weights only 11kg. In addition to this, it has excellent efficiency, low standby power, and a very quiet operation.
Display and Bluetooth
The display reads battery and inverter parameters.
The same parameters can be accessed with a smartphone or other Bluetooth-enabled device. In addition, Bluetooth can be used to set up the system and change settings with VictronConnect.
VE.Can and VE. Direct port
For connection to a GX device for system monitoring, data logging, and remote firmware updates.
Programmable relay, temperature sensor and voltage sensor connections. The remote input can also be configured to accept the Victron small BMS.
Configure & Monitor with VictronConnect
A built-in Smart Bluetooth connection allows for quick monitoring or settings adjustment of the inverter RS.
|Inverter RS Smart Solar||48/6000|
|DC Input voltage range||38 – 64 V (6)|
|Output||Output voltage: 230 VAC ± 2% Frequency: 50 Hz ± 0.1% (1)|
|Continuous output power at 25°C||Increases linearly from 4800 W at 46 VDC to 5300 W at 52 VDC|
|Continuous output power at 40°C||4500W|
|Continuous output power at 65°C||3000W|
|Peak power||9 kW for 3 seconds|
|Short-circuit output current||50A|
|Maximum efficiency||96.5% at 1 kW load 94% at 5 kW load|
|Zero load power||20W|
|Maximum DC voltage||450V|
|Nominal DC voltage||300V|
|MPPT operating voltage range||80 – 450V (5)|
|DC input current limit Maximum DC input current||18A (4) 20A|
|Maximum PV input power||4000W|
|Maximum DC charging power||4000W|
|Earth leakage trip level||30 mA|
Victron Energy warrants its products to be free from defects in workmanship and materials for a period of Batteries: 2-year limited warranty Li-ion batteries: 3-year limited warranty All other products: 5-year limited warranty.
