A simple wall-mounted energy storage solution
The ECOmulti can be wall mounted, is easy to install, easy to program, and easy to operate.
- Energy storage can be increased by adding battery modules.
- AC power can be increased by paralleling ECOmulti modules.
- Three ECOmulti modules can be configured for three-phase operation.
- Two ECOmulti modules can be configured for split-phase operation.
More self-consumption, more independence
With 2,3 kWh Li-ion storage capacity and a 3 kVA bidirectional inverter, the ECOmulti reduces dependence on power from the grid.
The growing interest in self-consumption is driven by increasing retail electricity prices and simultaneously decreasing feed-in tariffs. Feed-in tariffs are decreasing a. o. because it becomes increasingly difficult, and expensive, to ensure the stability of the grid as more solar and wind power comes online. Simultaneously, the retail price of electricity is increasing, to cover these same costs plus the cost to keep conventional power plants on hot standby to back-up renewable power generation in case the sun is not shining and/or the wind is not blowing.
During the night the ECOmulti is disconnected from the grid. The home is powered by energy stored in the battery. The ECOmulti will reconnect to the grid when the battery is discharged.
The next day, when the PV array produces sufficient power to supply the loads and to start charging the battery, the ECOmulti will regulate the charge current to absorb nearly 100% of the surplus PV power.
Discharging during the day
When PV output is reduced by clouds or when a power-hungry load is switched on, resulting in no surplus PV power available, battery charging will stop. Insufficient PV power will be supplemented by power from the ECOmulti. In case of overload, power will be imported from the grid to supplement power from the ECOmulti (GridAssist function), and system shutdown due to overload will be prevented.
Battery fully charged
Once the battery is fully charged, additional loads (for example the water heater) can be switched on, or surplus power will be exported to the grid.
End of the day
The ECOmulti disconnects from the grid about 10 minutes after PV power has become insufficient to provide any charge current. In order to prevent false disconnections due to lack of sun during the day, the inverter/charger also uses an internal timer to predict the end of the day.
When the grid fails, the ECOmulti will continue to power the home.
|Description||Victron ECOmulti Home Battery Storage Charger 24V 2.3kWh EMP243020200|
|Original Brand||Victron Energy EMP243020200|
|Chemistry||Lithium Ion (LiIon)|
Victron Energy warrants its products to be free from defects in workmanship and materials for a period of Batteries: 2-year limited warranty Li-ion batteries: 3-year limited warranty All other products: 5-year limited warranty.
