Description
The Blue Smart IP65 Charger is the new professional battery charger with built-in Bluetooth. The Blue Smart IP65 Charger can be used on devices in your workshop and on motor vehicles, such as (classic) cars; motorbikes; boats and camper-vans.
New: IP65 6V/12V 1.1A
New: IP65 12/5 replaced by smaller equivalent model: IP65s 12/5
Models
6V/12V 1.1A, 12V 4/5/7/10/15/25A, 24V 5/8/13A
FEATURES
The battery is charged, smartly... to perfect condition
The seven-step charging algorithm gets the best out of your battery. The charger gives the battery the power it needs, maintains its health, ensures better performance... and a longer life.
Recovery of deeply-discharged 'dead' batteries
Unlike other brands, the Blue Smart IP65 Charger will attempt to recharge a deeply-discharged battery by force-feeding it with a low current. Normal charging will then be resumed as soon as there is sufficient voltage across the battery terminals.
Connect the battery with ease
The charger comes with both crocodile clips and M8 eyelets - making it easy to connect to the battery. If you wish, you can leave it permanently connected.
Check the status of your battery remotely
The Blue Smart IP65 is equipped with built-in Bluetooth, so the status of the charger and the battery can be checked on a smartphone, tablet or laptop. All settings of the charger can be configured with the VictronConnect app.
SPECIFICATIONS
| Product Title |
Victron Blue Smart IP65 Charger 6V/12V-1.1 230V AU/NZ BPC120134014R |
|---|---|
| SKU | BPC120134014R |
| GTIN (Global Trade Item Number) | 8719076055150 |
| Brands | Victron |
| Product Category | Battery Chargers |
| Model | BPC120134014R |
| Output Current Rating (Amps) | 1.1 Amps |
| Efficiency | 82% |
| Operating Temperature Range | -30 to +50°C (full rated output up to 30°C) |
| Humidity | Max 95% |
| Output System Voltage | 12V |
| Back Current Drain | 0,1 Ah/month (140uA) |
| Charge current | 1.1 A |
| Temperature compensation (lead-acid batteries only) | 8 mV/°C | 16 mV/°C |
| Dimensions | 38mm x 64mm x 153 mm (h x w x d) |
| Net Weight (kg) | 0.4 Kg |
| Charge voltage 'absorption' | Normal: 7.2 V | High: 7.35 V | Li-ion: 7.1 V |
| Charge Voltage Float - Wet (25 degrees)** | Normal: 6.9 V | High: 6.9 V | Li-ion: Disabled |
| Charge voltage 'storage' | Normal: 6.6 V | High: 6.6 V | Li-ion: 6.75 V |
| Protection | Reverse polarity, Output short circuit, Over temperature |
| Charge current in low current mode | 0.5A |
| Protection category | IP65 (splash and dust proof) |
| Battery-connection | Black and red cable of 1,5 meter |
| Standby power consumption | 0.5 W |
| Input Voltage | 230VAC |
| Can be used as a power supply | Yes |
| Manufacturers Warranty | 5 Years |
WARRANTY
Victron Energy warrants its products to be free from defects in workmanship and materials for a period of: Batteries: 2 year limited warranty Li-ion batteries: 3 year limited warranty All other products: 5 -year limited warranty.
