Description
BPR000220400The Battery Protect disconnects the battery from non-essential loads before it is completely discharged (which would damage the battery) or before it has insufficient power left to crank the engine.
FEATURES
12/24V Auto Ranging
The BatteryProtect automatically detects system voltage
Programming made easy
The BatteryProtect can be set to engage / disengage at several different voltages. the seven-segment display will indicate which setting has been chosen.
A special setting for Li-ion batteries
In this mode, the BatteryProtect can be controlled by the VE.Bus BMS. Note: the BatteryProtect can also be used as a charge interrupter in between a battery charger and a Li-ion battery. See the connection diagram in the manual.
Ultra-low current consumption
Uses only 1.5ma when on and when off or due to low voltage shutdown uses only 0.6ma. This is important in the case of Li-ion batteries, especially after low-voltage shutdown
Over-voltage protection
To prevent damage to sensitive loads due to overvoltage, the load is disconnected whenever the DC voltage exceeds 16V (12V setting) and 32V (24V setting)
Ignition proof
The unit doesn't use relays but MOSFET switches instead, and therefore no sparks.
Delayed alarm output
The alarm output is activated if the battery voltage drops below the preset disconnect level during more than 12 seconds. Starting the engine will therefore not activate the alarm. The alarm output is a short circuit-proof open collector output to the negative (minus) rail, max. current 50 mA. The alarm output is typically used to activate a buzzer, LED, or relay.
Delayed load disconnect and delayed reconnect
The load will be disconnected 90 seconds after the alarm has been activated. If the battery voltage increases again to the connect threshold within this time period (after the engine has been started for example), the load will not be disconnected. The load will be reconnected 30 seconds after the battery voltage has increased to more than the preset reconnect voltage.
SPECIFICATIONS
| SKU | BPR000220400 |
| Model # | BPR000220400 |
| UPC/EAN | 8719076021452 |
| Brand | Victron Energy |
| Shipping Weight | 0.9770kg |
| Shipping Width | 0.150m |
| Shipping Height | 0.075m |
| Shipping Length | 0.150m |
| Shipping Cubic | 0.016875000m3 |
WARRANTY
Victron Energy warrants its products to be free from defects in workmanship and materials for a period of Batteries: 2-year limited warranty Li-ion batteries: 3-year limited warranty All other products: 5-year limited warranty.
