Description
FEATURES
- Cable-free, plug-and-play
- USB communication port
- Built-in memory for up to one month of data
- Online monitoring and maintenance
SPECIFICATIONS
| Product Name | Growatt Shine4G-X |
| Wireless Parameters | |
| Wireless Type | 4G |
| System and Frequency band | LTE-FDD: B1/B3/B5/B7/B8/B20 LTE-TDD: B38/B40/B41 WCDMA: B1/B5/B8 GSM: 900/1800MHz |
| Hardware Parameters | |
| Data interface | USB |
| Operating voltage | 5V(±5%) |
| Rated power | 1.2W |
| Display | LED |
| Application Parameters | |
| Supported servers | ShineServer |
| Inverter communication | USB (Modbus RTU protocol) |
| Server communication | TCP (Modbus TCP protocol) |
| Supported network | 2G/3G/4G |
| SIM card type | Standard SIM card |
| Configuration Type | APP Configuration |
| Data transmission interval | 5 Minutes |
| Default server URL | server.growatt.com |
| General Data | |
| Dimensions(L/W/H) | 122/47/32mm |
| Weight | 60g |
| Operating temperature | -30℃ ～ +65℃ |
