Description
Epower Pure sine wave inverter:
With ePOWER’s state of the art, easy to use design, this 400W 12V inverter will offer you reliable service for providing AC power for your home, boat, caravan, 4WD or commercial vehicle. The Enerdrive ePOWER 400W Inverter can run many AC powered appliances when you need AC power anywhere.
These inverters are the most sophisticated inverters on the market today. They are designed to precisely replicate and even improve on the quality of electricity supplied by utility companies. There is generally no compatibility issues with any appliance run from a pure sine wave power inverter.
FEATURES
- Australian GPO Outlets
- True sine wave output is ideal for operating motor loads, and to reduce stress on surge protection circuitry, meaning potentially longer equipment life
- Audio alarm with warning/error codes to alert user to check inverter condition before unit shutdown
- Automatic shutdown protects overload, over temperature and low/high battery conditions
- High surge capacity for products that require more power to start (2 x constant)
- High efficiency conversion of battery available power to AC power
- Mounting brackets for permanent installation
- Heavy duty DC battery stud connectors
SPECIFICATIONS
| Model – Description | ePOWER 400 | ePOWER 1000 | ePOWER 2000 |
| Part Number | EN1104S | EN1110S | EN1120S |
| AC Output Power | 400W | 1000W | 2000W |
| AC Output Current | 1.74A | 4.3A | 8.7A |
| AC Surge Power (Peak) | 800W | 2000W | 4000W |
| AC Output Voltage | 230 Vac / 50 Hz | ||
| AC Output Waveform | True Sinewave | ||
| AC Output Socket | 1 outlet | 1 outlet | 2 outlet |
| Nominal DC Input Voltage | 12.5 VDC | ||
| No Load battery draw | < 0.8 ADC | < 1.2 ADC | < 1.2 ADC |
| DC Input Voltage operating range | 10.5 – 15.5 VDC | ||
| Under Voltage Alarm | 11.2 VDC | ||
| Under Voltage Shutdown | 10.5 VDC | ||
| Under Voltage Recovery | 11.8 VDC | ||
| Over Voltage Shutdown | 15.5 VDC | ||
| USB | 5V, 1A | 5V, 750 mA | 5V, 750 mA |
| Safety and Environmental | |||
| Conformance | All required Australian Standards | ||
| Agency Markings | RCM | ||
| Operating Temperature | 0°C to 40°C | ||
| Storage Temperature | -20°C to 60°C | ||
| Relative Humidity | 5-90% noncondensing | ||
| Operating Altitude | Up to 3000 meters above sea level | ||
| Weights and Dimensions | |||
| Weight | 1.73Kg | 2.9Kg | 5.5Kg |
| Dimensions (W x L x H) | 177 x 200 x 90mm | 177 x 325 x 90mm | 230 x 416 x 110mm |
| Warranty | 5 Years | ||
