Victron Multi RS Solar 48/6000/100-450/80 1 Tracker PMR482602000


Price:
Sale price$4,451.00

Description

The Multi RS Solar 48/6000 is an Inverter Charger with a 450V Solar Charger on board. It also has a bi-directional DC-DC charger that charges the battery with excess solar power or converts power from the battery when required. The 4kWp Solar Charger can be daisy-chained to more Solar Chargers, with the possibility of synchronized charging; the Multi RS can also be connected to PV Inverters.

  • 80 – 450VDC input
  • Display. Data can also be read from a phone or Bluetooth device.
  • Extendable PV capacity – both AC and DC coupled.
  • Can be connected to a GX device via VE Can.
  • Can be connected to a GlobalLink 520 vie VE Direct

Thanks to high-frequency technology and a new design the powerful Multi RS Solar 48/6000 With 450V/4000W PV input inverter weighs only 11kg. In addition to this, it has excellent efficiency, low standby power, and a very quiet operation. It's a great solution for tiny homes, cabins, and larger motorhomes through to small houses.

The display reads battery, inverter, and solar parameters. The same parameters can be accessed with a smartphone or other Bluetooth-enabled device, using the VictronConnect app.

FEATURES

Hybrid Inverter/Charger
The Multi RS Solar 48/6000 is a 48 V 6 kVA Inverter/Charger with 450 VDC 4 kWp PV input.

Combination of an inverter, AC charger, and Solar MPPT
The inverter produces a perfect sinewave and is able to supply high-powered appliances. It is also bi-directional, charging the battery when excess solar power or AC supply is available, or converting from the battery when it is needed.

Wide MPPT voltage range
80 – 450 VDC, with a 120 VDC PV startup voltage.

Lightweight, efficient, and quiet
Thanks to high-frequency technology and a new design this powerful inverter weighs only 11 kg. In addition to this, it has excellent efficiency, low standby power, and a very quiet operation.

Display, Bluetooth, and VictronConnect app
The display reads battery, inverter, and solar parameters. The same parameters can be accessed with a smartphone or other Bluetooth-enabled device, using the VictronConnect app.

Extendable PV capacity, both AC-coupled and DC-coupled
The integrated 4 kW PV capacity can be extended by adding Solar Chargers to the system, for example, Victron Smart Solar Charger range, including the Smart Solar RS models. When connected in a VE.Can network, all battery charging will operate synchronously and coordinated. Alternatively, the PV capacity can be extended by installing PV Inverters, of which the output power will be automatically controlled by the integrated Frequency Shift Power Control.

Communication ports
VE. Can connect to a GX device for system monitoring, data logging, and remote firmware updates. VE.Direct connection to a GlobalLink 520 for remote data monitoring.

I/O Connections
Programmable Relay, temperature sensor, and voltage sensor connections. The remote input can also be configured to accept the Victron small BMS.

VRM Portal
When the Multi RS is connected to a GX device with an internet connection, you can access Victrons free remote monitoring website (VRM). This will display all your system data in a comprehensive graphical format. System settings can be changed remotely via the portal. Alarms can be received by e-mail.

SPECIFICATIONS

SKU PMR482602000
Model # PMR482602000
UPC/EAN 8719076054474
Brand Victron Energy
Shipping Weight 14.0000kg
Shipping Width 0.220m
Shipping Height 0.480m
Shipping Length 0.540m
Shipping Cubic 0.057024000m3

WARRANTY

Victron Energy warrants its products to be free from defects in workmanship and materials for a period of Batteries: 2-year limited warranty Li-ion batteries: 3-year limited warranty All other products: 5-year limited warranty.
