Victron Galvanic Isolator VDI Available in 2 Model Types


Model Type: VDI-32 GDI000032000
Warranty Option: Standard 5 Years Warranty
Price:
Sale price$483.00

Description

Product Name Victron Galvanic Isolator VDI-32 GDI000032000 Victron Galvanic Isolator VDI-64 GDI000064000
DESCRIPTIONS The galvanic isolator prevents electrolytic corrosion. It blocks low voltage DC currents that enter your boat via the shore power earth wire. These currents can cause corrosion to the boat’s underwater metals, like the hull, propeller, shaft and so on.  The galvanic isolator consists internally of two diodes which are connected in anti-parallel fashion. When they are connected in this way, the diodes allow current in both directions but only above a certain threshold voltage. The voltage at which diodes conduct is about 1.4 Vdc.
FEATURES The isolator is installed directly behind your boat's 230V connection.
  The forward voltage from the galvanic isolator is higher than the potential difference between metals.
  As a result, this voltage will not allow conduction and as such, the galvanic isolator will prevent any electrolytic current.
  However, if there is a (higher) error voltage in the AC circuit, the diodes will allow current through and the residual-current device will break the circuit.

SPECIFICATIONS

Product Name Victron Galvanic Isolator VDI-32 GDI000032000 Victron Galvanic Isolator VDI-64 GDI000064000
SKU GDI000032000 GDI000064000
GTIN (Global Trade Item Number) 8719076022381 8719076048107
Brands Victron
Product Category Batteries Other
Dimensions 200 mm x 164mm x 63 mm 335 mm x 164 mm x 63 mm
Weight (Kg) 5 3.2
Maximum Charge Current 32A 64A
Warranty 5 Years

WARRANTY

Victron Energy warrants its products to be free from defects in workmanship and materials for a period of Batteries: 2-year limited warranty Li-ion batteries: 3-year limited warranty All other products: 5-year limited warranty.

NOTE:

The option of a 10-year limited warranty can only be applied during the actual purchase of the product.
