Enerdrive TBS RCD Inverter Kit 350W 24V RCD-GPO-TBS350-24


Price:
Sale price$1,234.00

Description

With the changes to the Australian Electrical Standards, ASNZS 4763-2011 Safety of Portable Inverters, coming into effect on the 1st July 2013 and combined with the push from Work Place Health and Safety for RCD Protection for workers, Enerdrive have released our “ready to go” Pure Sine Wave Inverter Kits that will suit everyone’s needs.

Think you might like AC power in more than one spot in the Vehicle? Enerdrive have thought of this too. By utilising a clever AC Plug & Play GPO system you can quickly and easily add extra AC power points by just plugging them in. All power points are Double Pole with the system incorporating a Type ‘A’ RCDBO with M.E.N Protection for safety and compliance in all permanently mounted mobile applications.

Also available is the stand alone RCD/GPO arrangement for hardwired Inverters and Combi units like the Prosine, Magnasine and TBS. (190mm High x 178mm Wide).

These Inverter Packages are great for Professional Vehicles such as Telecommunications, Energy, Council, Emergency Vehicles and let’s not forget Recreation Vehicles like Caravans, Motorhomes, Camper Trailers and Marine applications.

“You have Safety Protection at home and now you can have it where ever you go.” Work sites have plenty of hazards such as vehicles, machinery and building materials lying amongst your tools and power leads. These items may be affected or damaged without you knowing and you don’t want to be shocked when you find out. Make sure you are electrically protected and go home safe.

Installation is quick and easy, requiring only 6 mounting screws for the plate and connection of the DC power. Your system is now ready to go.

FEATURES

  • True sine wave output is ideal for operating motor loads, and to reduce stress on surge protection circuitry, meaning potentially longer equipment life
  • Audio alarm with warning/error codes to alert user to check inverter condition before unit shutdown
  • Automatic shutdown protects overload, over temperature and low/high battery conditions
  • High surge capacity for products that require more power to start (2 x constant)
  • High efficiency conversion of battery available power to AC power
  • Heavy duty DC battery stud connectors
  • Includes 5V USB port

SPECIFICATIONS

Model – Description ePOWER 400 ePOWER 500 ePOWER 600 ePOWER 1000 ePOWER 2000
Part Number RCD-GP0-EP400W RCD-GP0-EP500W RCD-GP0-EP600W RCD-GP0-EP1000W RCD-GP0-EP2000W
AC Output Power 400W 500W 600W 1000W 2000W
AC Output Current 1.74A 2.17A 2.6A 4.3A 8.7A
AC Surge Power (Peak) 800W 1000W 900W 2000W 4000W
AC Output Voltage 230 Vac / 50 Hz
AC Output Waveform True Sinewave
AC Output Socket 1 outlet 2 outlets
Nominal DC Input Voltage 12.5 VDC 25 VDC 12.5 VDC
No Load battery draw < 0.8 ADC < 0.5 ADC < 0.8 ADC < 1.2 ADC
DC Input Voltage operating range 10.5 – 15.5 VDC 21.0 – 31.0 VDC 10.5 – 15.5 VDC
Under Voltage Alarm 11.2 VDC 11.2 VDC 11.2 VDC
Under Voltage Shutdown 10.5 VDC 21.0 VDC 10.5 VDC
Under Voltage Recovery 11.8 VDC 23.6 VDC 11.8 VDC
Over Voltage Shutdown 15.5 VDC 31.0 VDC 15.5 VDC
USB 5V, 1A 5V, 1A 5V, 1A 5V, 750 mA 5V, 750 mA
Safety and Environmental
Conformance All required Australian Standards
Agency Markings RCM
Operating Temperature 0°C to 40°C
Storage Temperature -20°C to 60°C
Relative Humidity 5-90% noncondensing
Operating Altitude Up to 3000 meters above sea level
Weights and Dimensions
Weight 1.73Kg 1.73Kg 1.73Kg 2.9Kg 5.5Kg
Dimensions (W x L x H) 225 x 410 x 115mm 225 x 410 x 115mm 225 x 410 x 115mm 228 x 521 x 115mm 285 x 621 x 135mm
Warranty 3 Years
Load Consumption Estimate Run time
Cordless Phone 5W 80 hrs
Clock/Radio 8W 65 hrs
Table Lamp 40W/60W 22 hrs/ 15 hrs
Freezer (8.8 cu. ft.) 80W 12 hrs
20″ LCD TV 100W 10.5 hrs
Refrigerator (18 cu. ft.) 120W 8.3 hrs
Microwave (mid-size) 1000W 44 min
Coffee Maker 1200W 35 min
Vacuum 1400W 28 m



NOTE:

This bundle is made to order. Please give us at least 6 weeks to prepare.
